12 english
Fig. 08.1
In case of deviations adjust as follows.
• Loosensixfoldscrews(1)
• Alignslitwedgevertically
• Slightlytightensixfoldscrews(1)
• Alignthe slitwedge tothe sawblade andtightenthe
sixfold screws (1) again.
Longitudinal end stop, Fig. 09
Screw the middle plate onto the end stop pipe. Do not
tighten!
2 flat edge screws M6 x 50
2 discs ø 6
2 wing nuts M6
Slide in end stop rail and wedge.
Position 1 = high installation surface
Position 2 = low installation surface
Put the longitudinal end stop in the clamping appliance.
Clamp = pull clamping flap up
Unfasten = push clamping flap down
Electrical connection
The installed electrical motor is connected ready to operate.
The connection complies with the relevant VDE- and DIN-
regulations.
The power supply as well as the used extension cable
should comply with these regulations.
Motor-brake facility
Your construction circular saw is equipped with an
automatically functioning deadlock brake. The brake starts
functioning after switching off the motor.
Important information
The electrical motor is made for operating mode S 6 / 40
% .
When the motor gets overcharged, it automatically switches
off. After a short cool-down period (time varies) the motor
can be switched on again.
Defective electrical power supply cords
Electrical power supply cords often suffer insolation
damages. Causes are:
• Pressurespots,whenpowersupplycordsarebeingled
through windows or doors.
• Bucklingspotsbyincorrectattachmentorguidanceof
the power supply cords.
•Cuttingsbydrivingoverapowersupplycord.
•Insulationdamagesthroughpullingoutofthesocket.
•Cracksinwornoutinsulation.
Such defective electrical power supply cords should not be
used and are extremely dangerous because of the insulation
damage.
Check electrical power supply cords for damages on a
regular basis. Please observe that upon checking the power
supply cord is not plugged in. Electrical power supply
cords have to comply with the relevant VDE - and DIN-
regulations. Only use power cables with the qualification H
07 RN. An imprint of the type denomination is rule.
Alternating current motor, Page U5
• Thesupplyvoltageshouldbe230Volt/50Hz.
• Extensioncablesmustbeupto25mlong,haveacross
cut of 1.5 square millimeter, be over 25 m long, and
have a minimum 2.5 square millimeter.
• Thepowersupplyshouldbe16A.
Rotary current motor, Page U5
• Thepowersupplyshouldbe400Volt/50Hz.
• Thepowersupplyandtheextensioncablesmustbe5
fold leads = 3 P + N + SL.
• Extension cables must have a minimum cable cross
section of 1.5 square millimeter.
• Thepowersupplyshouldbemaximum16A.
• Incaseofconnectiontothepowersupplyormovingsite
the rotary direction should be checked, otherwise the
polarity has to be changed (wall mounted connector).
Therefore screw the phase switcher into the plug
surrounding with a screw driver. (See Fig. 10)
Connections and repairs of the electrical equipment should
only be carried out by an electrical specialist.
In case you have further questions, please specify the
following:
•Motormanufacturer
•Currenttypeofthemotor
•Informationofthemachinetypelabel
•Informationoftheswitchtypelabel
When sending back the motor, always return the complete
power unit with switch.
Implementation
Please read the safety information before implementation.
The implementation of the machine is only admissable
when protection and safety facilites have been installed
completely.
Put the machine on a stable, even floor. If necessary attach
through the bottom through the holes to the frame valves.
(screws/nails)
After connection to the power supply your scheppach
construction circular saw is ready to operate.
