www.scheppach.com
36
|
GB
Driving link thickness 0,043
Chain wheel tooth pitch 1/4” / 6
Protection class II
Weight unfuelled, without cutting
gear approx.
1.0 kg
Weight unfuelled, with cutting
gear approx.
1.13 kg
Technical changes reserved!
Noise and vibration
m Warning: Noise can have serious effects on your
health. If the machine noise exceeds 85 dB (A), please
wear suitable hearing protection.
Noise data
Sound power level L
WA
96,2dB(A)
Sound pressure level L
pA
89,6dB(A)
Uncertainty K
wa/pA
3dB(A)
Vibration parameters
Vibration a
h
4,43m/s
2
Uncertainty K
h
1,5
8. Unpacking
• Open the packaging and carefully remove the prod-
uct.
• Remove the packaging material, as well as the pack-
aging and transport safety devices (if present).
• Check whether the scope of delivery is complete.
• Check the product and accessory parts for transport
damage. In the event of complaints the carrier must
be informed immediately. Later claims will not be
recognised.
• If possible, keep the packaging until the expiry of the
warranty period.
• Familiarise yourself with the product by means of the
operating manual before using for the rst time.
• With accessories as well as wearing parts and re-
placement parts use only original parts. Replace-
ment parts can be obtained from your dealer.
• When ordering please provide our article number as
well as type and year of manufacture for the product.
m WARNING!
The device and the packaging material are not
children‘s toys! Do not let children play with plas-
tic bags, lms or small parts! There is a danger of
choking or suffocating!
Information on the charging unit and charging pro-
cess
• Please observe the operating manual for the charg-
ing unit.
6. Residual risks
The machine has been built according to the state-of-
the-art and the recognised technical safety require-
ments. However, individual residual risks can arise
during operation.
• Health hazard due to electrical power, with the use
of improper electrical connection cables.
• Furthermore, despite all precautions having been
met, some non-obvious residual risks may still re-
main.
• Residual risks can be minimised if the “Safety In-
structions” and the “Intended Use” together with the
operating manual as a whole are observed.
• Avoid accidental starting of the machine: the operating
button may not be pressed when inserting the plug in
an outlet. Use the tool attachment that is recommend-
ed in this operating manual. This is how to ensure that
your machine provides optimum performance.
• Keep your hands away from the working area when
the machine is in operation.
The following hazards may arise in connection with the
design and construction of this power tool:
• Cuts
• Hearing damage if suitable hearing protection is not
worn.
• Damage to health resulting from hand/arm vibration
if the device is used over an extended period of time
or if it is not properly operated and maintained.
7. Technical data
Motor voltage 20 V DC
Engine output 0.4 W
Type of guide bar (pre-tted)
ROYAL 6”
CLQ4336
Type of saw chain (pre-tted)
ROYAL 6” DH06-
36-43P
Tank for chain lubricating oil
ca. 40 cm³ (40
ml)
Max. cutting speed 7.5 m/s
Chain pitch
1/4”/1,1mm
