14. Electrical connection
The electrical motor installed is connected and
ready for operation. The connection complies with
the applicable VDE and DIN provisions. The cus-
tomer‘s mains connection as well as the extension
cable used must also comply with these regula-
tions.
Important information
In the event of an overloading the motor will switch itself
off. After a cool-down period (time varies) the motor can be
switched back on again.
Damaged electrical connection cable.
The insulation on electrical connection cables is often dam-
aged.
This may have the following causes:
• Passage points, where connection cables are passed through
windows or doors.
• Kinks where the connection cable has been improperly fas-
tened or routed.
• Places where the connection cables have been cut due to
being driven over.
• Insulation damage due to being ripped out of the wall outlet.
• Cracks due to the insulation ageing.
Such damaged electrical connection cables must not be used
and are life-threatening due to the insulation damage.
Check the electrical connection cables for damage regularly.
Make sure that the connection cable does not hang on the
power network during the inspection.
Electrical connection cables must comply with the applicable
VDE and DIN provisions. Only use connection cables with the
marking „H05VV-F“.
The printing of the type designation on the connection cable
is mandatory.
AC motor:
The mains voltage must be 230 V
~
.
• Extension cables up to 25 m long must have a cross-section
of 1.5 mm
2
.
Connections and repairs of electrical equipment may only be
carried out by an electrician.
Please provide the following information in the event of any
enquiries:
• Type of current for the motor
• Machine data - type plate
15. Disposal and recycling
The equipment is supplied in packaging to prevent it from being
damaged in transit. The raw materials in this packaging can be
reused or recycled.
The equipment and its accessories are made of various types
of material, such as metal and plastic. Defective components
must be disposed of as special waste. Ask your dealer or your
local council!
The packaging is wholly composed of environment-
ally-friendly materials that can be disposed of at a
local recycling centre.
Contact your local refuse disposal authority for
more details of how to dispose of your worn-out
electrical devices.
Old devices must not be disposed of with house-
hold waste!
This symbol indicates that this product must not be dis-
posed of together with domestic waste in compliance
with the Directive (2012/19/EU) pertaining to waste
electrical and electronic equipment (WEEE). This prod-
uct must be disposed of at a designated collection point. This
can occur, for example, by handing it in at an authorised col-
lecting point for the recycling of waste electrical and electronic
equipment. Improper handling of waste equipment may have
negative consequences for the environment and human health
due to potentially hazardous substances that are often con-
tained in electrical and electronic equipment. By properly dis-
posing of this product, you are also contributing to the effective
use of natural resources. You can obtain information on collec-
tion points for waste equipment from your municipal administra-
tion, public waste disposal authority, an authorised body for
the disposal of waste electrical and electronic equipment or
your waste disposal company.
Batteries and rechargeable batteries do not be-
long in the household waste!
As the consumer you are required by law to bring all
batteries and rechargeable batteries, regardless
whether they contain harmful substances* or not, to a
collection point run by the local authority or to a retailer, so that
they can be disposed of in an environmentally friendly manner.
*labelled with: Cd = cadmium, Hg = mercury, Pb = lead
Remove the batteries from the laser before disposing of the
machine and the batteries.
