Scheppach DP19Vario User Manual

www.scheppach.com
GB
|
29
Laser class 2
Laser wavelength 650mm
Power of laser 1mW
Technical changes reserved!
Noise and vibration
The noise values have been determined in accordance
with EN 62841.
Sound pressure level L
pA
73,8 dB(A)
Uncertainty K
pA
3 dB(A)
Sound power level L
WA
86,8 dB(A)
Uncertainty K
WA
3 dB(A)
Wear hearing protection.
Excessive noise can result in a loss of hearing. Total
vibration values (vector sum of three directions) deter-
mined according to EN 62841.
Vibration emission value a
h
1.7 m/s
2
Uncertainty K = 1,5 m/s
2
The specied vibration emission value has been meas-
ured according to a standardised testing procedure
and can be used for comparison of one power tool with
another; and may change depending on the way in
which the power tool is used and in exceptional cases
may be higher than the specied value.
The specied vibration emission value can be used to
compare one power tool with another.
The specied vibration emission value can also be
used for an initial estimation of the impair.
7. Before commissioning
• Open the packaging and carefully remove the de-
vice.
• Remove the packaging material, as well as the pack-
aging and transport safety devices (if present).
• Check whether the scope of delivery is complete.
• Check the device and accessory parts for transport
damage. In the event of complaints the carrier must
be informed immediately. Later claims will not be
recognised.
• If possible, keep the packaging until the expiry of the
warranty period.
Residual risks
The electric tool has been built according to state-
of-the-art and the recognised technical safety
rules. However, individual residual risks can arise
during operation.
• Health hazard due to electrical power, with the use
of improper electrical connection cables.
• Furthermore, despite all precautions having been
met, some non-obvious residual risks may still re-
main.
• Residual risks can be minimised if the “Safety in-
structions” and “Proper use” are observed along
with the whole of the operating instructions.
• Do not load the machine unnecessarily: too much
pressure when drilling quickly damages the tool at-
tachment. This can lead to a reduction in the per-
formance of the machine during machining and a
reduction in accuracy.
• Avoid accidental starting of the machine: the oper-
ating button may not be pressed when inserting the
plug in an outlet.
• Use the tool that is recommended in this manual.
This is how to ensure that your device provides opti-
mum performance.
• Keep your hands away from the work area, when the
machine is in operation.
• Before maintaining or adjusting, switch o󰀨 the ma-
chine and unplug the power plug.
6. Technical data
Rated input voltage 230-240V~ 50 Hz
Nominal power 550 W
Motor speed 1490 min
-1
Output speed
(continuously adjustable)
440 - 2580 min
-1
Chuck adapter B16
Chuck 1.5 - 13 mm.
Drilling table size 190 x 190 mm
Angle adjustment 45° - 0° - 45°
Drilling depth 60 mm
Column diameter 59.5 mm
Height 870 mm
Weight 27 kg

Scheppach DP19Vario Specifications

General

Drilling	Yes
Chuck type	Keyless
Hammer drilling	No
Adjustable torque	-
Product color	Black, Blue, Red
Idle speed (max)	2580 RPM
Idle speed (min)	440 RPM
Chuck capacity (max)	16 mm
Chuck capacity (min)	1 mm
Drilling diameter in wood (max)	- mm
Input power	550 W

Weight and Dimensions

Depth	730 mm
Width	500 mm
Height	300 mm
Weight	31400 g
