15 І 40
lntended use
The intended use of this power tool is the sanding of
large areas of drywalls as a preparation before pain-
ting or wallpapering using suitable abrasive sheets.
This power tool is neither suited for the preparation of
small areas, corners and edges, nor for the removal
of wallpaper and the grinding of ceilings and wet grin-
ding.
Do not use the power tool for cutting or roughing or
polishing. Do not use it together with wire brushes. Do
not treat asbestos containing materials with this power
tool.
This power tool is solely intended for private use. Da
not use the power tool for any other purpose than for
the intended one. Any other use beyond the intended
use is im proper.
For any resulting darnage or injury, the user/Operator
is held liable, not the manufacturer.
Technical Data
Nominal voltage: 230 V
Nominal frequency: 50 Hz
Power consumption: 710 W
Nominalspeed (oscillation ra-
te) n:
700 - 1700 1/min
Spindie size: M14
Grinding disc diameter: 210 mm
Abrasive paper diameter: 214 mm
Protection class: II
Weight.: approx 4.5 kg
Sound level
Sound pressure Ievel L
PA
.: 78 dB(A)
Sound power Ievei L
WA
.: 89 dB(A)
Uncertainty K 3 dB(A)
Hand-arm vibration
When grinding with abrasive
sheets a
h
2.28 m/s
2
Uncertainty K: 1.5 m/s
2
The specied hand-arm vibration value is based on
grinding with an abrasive sheet. Different applications
may result in different values.
The noise and vibration values were determined ac-
cording to EN 60745-1 and EN 60745-2-3.
The specied vibration value was measured an the
basis of a standard test method and can be used to
compare any kind of power tools.
The specied vibration value can also be used for the
initial evaluation of exposure.
Warning! Depending on how you use the power
tool, the actual vibration values may deviate from
the specied values!
Take measures to protect yourself against vibra-
tions!
Make sure to take into account the entire work pro-
cess, i.e. also times when the power tool is opera-
ted without Ioad or switched off! Appropriate mea-
sures include the regular maintenance and care of
the power tool and its attachments, keeping your
hands warm, regular breaksandweil planned work
processes!
Introduction
MANUFACTURER
scheppach
Fabrikation von Holzbearbeitungsmaschinen GmbH
Günzburger Straße 69
D-89335 Ichenhausen
DEAR CUSTOMER,
We wish you much joy and success in working with your
new device.
NOTE:
According to the applicable product liability laws, the
manufacturer of the device does not assume liability
for damages to the product or damages caused by the
product that occurs due to:
• Improper handling,
• Non-compliance of the operating instructions,
• Repairs by third parties, not by authorized service
technicians,
• Installation and replacement of non-original spare
parts,
• Application other than specied,
• A breakdown of the electrical system that occurs
due to the non-compliance of the electric regulations
and VDE regulations 0100, DIN 57113 / VDE0113.
We recommend:
Read through the complete text in the operating
instructions before installing and commissioning the
device. The operating instructions are intended to help
the user to become familiar with the machine and take
advantage of its application possibilities in accordance
with the recommendations. The operating instructions
contain important information on how to operate the
machine safely, professionally and economically, how
to avoid danger, costly repairs, reduce downtimes
and how to increase reliability and service life of the
machine.
In addition to the safety regulations in the operating
instructions, you have to meet the applicable regulati-
ons that apply for the operation of the machine in your
country. Keep the operating instructions package with
the machine at all times and store it in a plastic cover
to protect it from dirt and moisture. Read the instruc-
tion manual each time before operating the machine
and carefully follow its information. The machine can
only be operated by persons who were instructed
concerning the operation of the machine and who are
informed about the associated dangers. The minimum
age requirement must be complied with.

Scheppach DS920 Specifications

General

Input power	710 W
AC input voltage	230 V
AC input frequency	50 Hz
Idle speed (max)	- RPM
Grinding wheel type	Dry grinding wheel
Grinding wheel 2 type	Not available
Grinding wheel diameter	210 mm
Number of grinding wheels	6
Adjustable speed	Yes
Country of origin	Germany

Weight and Dimensions

Depth	730 mm
Width	290 mm
Height	260 mm
Weight	6360 g
