7. Before starting the equipment
Make sure the machine stands securely, i.e. bolt it to a
workbench or solid base. There are two holes for this
purpose in the machine foot.
• The saw table must be mounted correctly.
• All covers and safety devices have to be properly
tted before the machine is switched on.
• It must be possible for the blade to run freely.
• When working with wood that has been processed
before, watch out for foreign bodies such as nails
or screws etc.
• Before you actuate the On/O󰀨 switch, make sure
that the saw blade is correctly tted and that the ma-
chine’s moving parts run smoothly.
• Before you connect the machine to the power sup-
ply, make sure the data on the rating plate is the
same as that for your mains.
8. Attachment
m ATTENTION! Before all maintenance, set-up and
assembly work on the band saw, unplug the mains
plug.
Assembly tools
1 Open-ended spanner, size 10/13
1 Allen key, size 3
1 Allen key, size 4
1 Screwdriver
The saw table and table extension are not assembled
for packaging reasons.
8.1 Assembling the saw table (Fig. 2-3)
• Remove the wing nut (21), the locking handle (22),
the two washers and the clamping plate (23). (Fig. 2)
• Guide the saw table (7) over the Bandsaw blade
(26). Fasten it to the two screws on the machine
frame with the plate (23), the two washers, the wing
nut (21) and the locking handle (22). (Fig. 3)
• Fit the bolt M6x35 (36) with two washers (37) and
the nut (38) to the table. (Fig. 3)
8.2 Fitting the table width enlargement
(Fig. 4 + 4.1 + 4.2 + 4.3 + 4.4)
• Remove the two bolts (39) and washers (40) from
the table width enlargement (8). (Fig. 4)
• Slide the table width enlargement (8) onto the table
(7) mounted on the machine. Ensure that the clamp-
ing lever (10) is open (Fig. 4.1+4.2).
6. Technical data
Electro motor 230 - 240 V ~ 50 Hz
Power
S1* 250W,
S2** 30 min 350W
Revolutions n0 1400 min
-1
Saw band length 1400 mm
Saw band width 3.5 - 12 mm
Saw band width max. 12 mm
Cutting speed 900 m/min
Passage height 0 - 80 mm
Passage width 200 mm
Table size 300 x 300 mm
Table size with min.
extension
380 x 300 mm
Table size with max.
extension
535 x 300 mm
Slewing range of the table 0° - 45°
Max. size of the workpiece 400 x 400 x 80 mm
Overall weight 19 kg
Subject to technical modications!
* Operating mode S1, continuous operation
** Operating mode S2, short-term operation with con-
stant load; Duration of nominal operation
The work piece must have a minimum height of 3 mm
and a minimum width of 10 mm.
The total noise values determined in accordance with
EN 61029.
Sound pressure level L
pA
77.4 dB(A)
Uncertainty K
pA
3 dB
Sound power level L
WA
90.4 dB(A)
Uncertainty K
WA
3 dB
Wear hearing protection!
The e󰀨ects of noise can cause a loss of hearing. Total
vibration emission values (vector sum of three direc-
tions) determined per EN 61029.

Scheppach HBS30 Specifications

General

Product type	Vertical band saw
Product color	Blue, Grey
Built-in light	-
Adjustable speed	Yes
Housing material	Steel, Aluminium
Table bevel angle	0 - 45 °
Input power	350 W
Power source	AC
AC input voltage	230 - 240 V
AC input frequency	50 Hz
Cutting width	- mm
Cutting height @ 90°	80 mm
Number of teeth per inch (TPI)	6, 10, 15

Weight and Dimensions

Depth	730 mm
Width	420 mm
Height	540 mm
Weight	20500 g
Table depth	520 mm
Table width	300 mm
