Scheppach HC53dc User Manual

www.scheppach.com
GB
|
25
• Avoid long air lines and supply lines (extension ca-
bles).
• Make sure that the intake air is dry and dustfree.
• Do not install the compressor in a damp or wet
room.
• The compressor may only be used in suitable rooms
(with good ventilation and an ambient temperature
from +5 °C to 40 °C). There must be no dust, ac-
ids, vapors, explosive gases or inammable gases
in the room.
• The compressor is designed to be used in dry
rooms. It is prohibited to use the compressor in ar-
eas where work is conducted with sprayed water.
• The oil level in the compressor pump has to be
checked before putting the equipment into opera-
tion.
• The compressor may only be used outdoor briey
when the ambient conditions are dry.
• The compressor must always be kept dry and must
not be left outdoors after work is complete.
8. Attachment and operation
m Important!
You must fully assemble the appliance before using it
for the rst time!
You will require the following tools for assembly and
installation:
• 2 x open-ended wrench size 17 mm (not included)
• 2 x open-ended wrench size 14 mm (not included)
8.1 Fitting the wheels (Fig. 5)
• Fit the supplied wheels (11) as shown.
8.2 Fitting the supporting foot (2x) (Fig. 6)
• Fit the supplied supporting foot (2x) as shown.
8.3 Fitting the air lter (2x) (Fig. 7, 8)
• Remove the transportation stop (A) and screw the
air lter (14) to the equipment.
8.4 Changing the transportation cover (B)
(Fig. 9, 10)
• Remove the transport lid (B) of the oil lling open-
ing (19).
• Fill the included compressor oil into the crank hous-
ing and insert the included oil sealing plug (15) into
the oil lling opening (19).
6. Technical data
Mains connection 230 V~ 50 Hz
Motor rating 2200 W
Operating mode S1
Compressor speed 2850 min
-1
Pressure vessel capacity 50 l
Operating pressure approx. 10 bar
Theoretical intake capacity approx. 412 l/min
Effective delivery quantity at
1 bar
approx. 294 l/min
Protection type IPX2
Weight of the unit approx. 41.5 kg
Oil (15W 40) l approx. 0.25 l
Max. altitude
(above mean sea level)
1000 m
The noise emission values were measured in accord-
ance with EN ISO 3744.
Wear hearing protection.
The effects of noise can cause a loss of hearing.
m Warning: Noise can have serious effects on your
health. If the machine noise exceeds 85 dB (A), please
wear suitable hearing protection.
Sound power level L
wA
91.3 dB(A)
Sound pressure level L
pA
71.2 dB(A)
Uncertainty K
wA/pA
2.03 dB(A)
7. Before starting the equipment
• Before you connect the equipment to the mains sup-
ply make sure that the data on the rating plate are
identical to the mains data.
• Prior to initial commissioning, remove the transport
plug (B) and ll the crank housing with oil as de-
scribed in item 8.4.
• Check the equipment for damage which may have
occurred in transit. Report any damage immediately
to the transport company which was used to deliver
the compressor.
• Install the compressor near the point of consump-
tion.
