• Do not load the product unnecessarily: excessive
pressure when sawing will quickly damage the saw
blade, which results in reduced output of the product
in the processing and in cut precision.
• When cutting plastic material, please always use
clamps: the parts which should be cut must always be
fixed between the clamps.
•
Avoid accidental start-up of the product: when inserting
the plug into the socket, do not press the on/off switch.
• Use the product in the way that is recommended in
this operating manual. This is how to ensure that your
product provides optimum performance.
• Keep your hands away from the working area when
the product is in operation.
• Before performing setting or maintenance work, re-
lease the on/off switch and pull out the mains plug.
WARNING
This power tool generates an electromagnetic field
during operation. This field can impair active or passive
medical implants under certain circumstances. In order
to prevent the risk of serious or deadly injuries, we rec-
ommend that persons with medical implants consult
with their physician and the manufacturer of the medical
implant prior to operating the power tool.
6 Technical data
Cross-cut mitre saw:
AC motor 220 - 240 V~ 50 Hz
Nominal power S1 1200 Watts
Operating mode S6 25%* 1500 W
Idle speed n
0
4900 rpm
Carbide saw blade ø 210 x ø 30 x 2.6 mm
Number of teeth 24
Maximum tooth width of
the saw blade
3 mm
Pivot range -45 ° / 0° / +45 °
Mitre cut 0° to 45° to the left
Saw width at 90° 120 x 60 mm
Saw width at 45° 80 x 60 mm
Saw width at 2 x 45°
(double mitre cut)
80 x 35 mm
Protection class
II / (Double insulation)
Weight approx. 6.5 kg
Laser:
Laser class 2
Laser wavelength 650 nm
Power of laser < 1 mW
Battery:
Battery type LR03
Nominal capacity 2000 mAh
Rated voltage 1.5 V
Size Micro AAA
Subject to technical changes!
Operating mode S6
Uninterrupted periodic operation. The mode comprises of
a start-up period, a time with constant load and an idle
time. The operating time is 10 mins, the relative duty cy-
cle is 25% of the operating time.
The workpiece must have a minimum height of 3 mm
and a minimum width of 10 mm. Make sure that the
workpiece is always secured with the clamping de-
vice.
Noise data
WARNING
Noise can have serious effects on your health. If the
machine noise exceeds 85 dB, please wear suitable
hearing protection for you and persons in the vicinity.
The noise and vibration values have been determined in
accordance with EN 62841-1.
Sound pressure level L
pA
91.6 dB
Uncertainty K
pA
3 dB
Sound power level L
wA
104.6 dB
Uncertainty K
wA
3 dB
The specified noise emission values have been measured
in accordance with a standardised test procedure and can
be used to compare one power tool with another.
The specified device emissions values can also be used
for an initial estimation of the load.
WARNING
The noise emission values can vary from the
specified values during the actual use of the
power tool, depending on the type and the
manner in which the electric tool is used, and
in particular the type of workpiece being pro-
cessed.
Try to keep the stress as low as possible. For example:
Limit working time. In doing so, all parts of the operating
cycle must be taken into account (such as times in
which the power tool is switched off or times in which it
is switched on, but is not running under a load).
7 Unpacking
• Open the packaging and carefully remove the product.
• Remove the packaging material, as well as the pack-
aging and transport safety devices (if present).
• Check whether the scope of delivery is complete.
• Check the product and accessory parts for transport
damage. Immediately report any damage to the trans-
port company that delivered the Product. Later claims
will not be recognised.
ATTENTION
The product and the packaging material are
not children's toys! Do not let children play
with plastic bags, films or small parts! There
is a danger of choking or suffocating!
GB | 27www.scheppach.com
