m ATTENTION!
The device and packaging materials are not toys!
Children must not be allowed to play with plastic
bags, lm and small parts! There is a risk of swal-
lowing and su󰀨ocation!
• The equipment must be set up where it can stand
securely. Secure the machine on a workbench or a
base frame with 4 screws (not included in delivery)
using the holes on the xed saw table (15).
• Pull out the pre-installed tilt protection (37) comple-
tely and secure it with an Allen key (D).
• All covers and safety devices have to be properly
tted before the equipment is switched on.
• It must be possible for the blade to run freely.
• When working with wood that has been processed
before, watch out for foreign bodies such as nails
or screws, etc.
• Before you press the ON/OFF switch check that the
saw blade is tted correctly. Moving parts must run
smoothly.
• Before you connect the equipment to the power sup-
ply make sure the data on the rating plate are denti-
cal to the mains data.
7.1 Checking the moving saw blade guard safety
device (5)
The saw blade guard protects against accidental con-
tact with the saw blade and from chips ying around.
Check function
To do so, fold the saw downwards:
• The saw blade guard must provide free access to
the saw blade without touching other parts.
• When folding the saw upwards into the starting posi-
tion, the saw blade guard must cover the saw blade
automatically.
8. Attachment and operation
m Attention!
Always make sure the device is fully assembled
before commissioning!
8.1 Attaching the crosscut, drag and mitre saw
(g. 1/2/4/5)
• In order to adjust the rotary table (14), loosen the
handle (11) approximately 2 turns and pull up the lat-
ched position lever (35) with your index nger.
The work piece must have a minimum height of 3
mm and a minimum width of 10 mm.
Make sure that the workpiece is always secured
with the clamping device.
Noise
Total noise values determined in accordance with
EN 62841.
Sound pressure level L
pA
101.6 dB
Uncertainty K
pA
3 dB
Sound power level L
WA
114.6 dB
Uncertainty K
pA
3 dB
Wear hearing protection.
The e󰀨ects of noise can cause a loss of hearing
The above-mentioned noise emission values were
measured in accordance with a standardised test pro-
cedure and can be used to compare one power tool
with another.
The above-mentioned noise emission values can also
be used for the preliminary assessment of exposure.
m WARNING:
• The noise emissions during the actual use of the
power tool may di󰀨er from the above-mentioned
values depending on the power tool being used, in
particular on the type of workpiece being processed.
• Try to keep emissions as low as possible, for exam-
ple by limiting your working time. In this regard, all
the operational cycle phases must be taken into
consideration (such as the times when the tool is
switched o󰀨 or running idle).
7. Before starting the equipment
• Open the packaging and remove the device care-
fully.
• Remove the packaging material as well as the pa-
ckaging and transport bracing (if available).
• Check that the delivery is complete.
• Check the device and accessory parts for trans-
port damage.
• If possible, store the packaging until the warranty
period has expired.

Scheppach HM254 Specifications

General

Laser guide	Yes
Product color	Blue, Grey
Sliding rails	-
Number of blade teeth	60
Input power	2000 W
Power source	AC
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Idle speed (max)	- RPM
Cutting width (90°)	340 mm

Weight and Dimensions

Depth	820 mm
Width	480 mm
Height	410 mm
Weight	17560 g
