Scheppach HS410 User Manual

www.scheppach.com
28
|
GB
Characteristic noise emission values
Sound power level L
WA
115 dB(A) (EN ISO 3744)
Sound pressure level L
pA
101 dB(A) (EN ISO 11201)
Uncertainly K
pA
4 dB(A)
8. Unpacking
m ATTENTION!
The device and packaging materials are not toys!
Children must not be allowed to play with plastic
bags, lm and small parts! There is a risk of swal-
lowing and su󰀨ocation!
• Open the packaging and remove the device care-
fully.
• Remove the packaging material as well as the pack-
aging and transport bracing (if available).
• Check that the delivery is complete.
• Check the device and accessory parts for transport
damage. In case of complaints the dealer must be
informed immediately. Subsequent complaints will
not be accepted.
• If possible, store the packaging until the warranty
period has expired.
• Read the operating manual to make yourself familiar
with the device prior to using it.
• Only use original parts for accessories as well as for
wearing and spare parts. Spare parts are available
from your specialized dealer.
• Specify our part numbers as well as the type and
year of construction of the device in your orders.
9. Attachment / Before starting
the equipment
m IMPORTANT!
You must fully assemble the appliance before us-
ing it for the rst time!
9.1 Assembly
9.1.1 Swivel frame (9) (g. 4 - 8)
Position the (right) guard (18) at the outer side of the
fastening and the saw blade guard 1 (20) at the inner
side of the fastening. Fasten the two steel panel parts
with three at, rounds screws and nuts (A1). Fasten
the guard (18) to the swivel frame with the hex screws
and nuts (A2). (g. 4 - 5)
Repeat this process to t the (left) guard (19) and saw
blade guard 2 (21). (g. 6 - 7)
• Avoid accidental starts of the machine: Do not press
the start button while inserting the plug into the
socket.
• Use the tools recommended in this manual to obtain
the best results from your machine.
• Always keep hands away from the work area when
the machine is running.
Note!
For your safety in the workplace, fasten the saw to
the oor with screws or bolts to prevent it tipping
or sliding.
7. Technical data
Motor 230 V / 50 Hz
Performance input P1 2,2 kW
Output power P2 1,5 kW
Operation mode S2 15 min
Rated idling revolution
speed
2800 min
-1
Engine brake yes
Engine brake type mechanical
Dimensions L x W x H 1002 x 737 x 1046 mm
Sawblade 405/30/3,2 mm Z32
Weight 39 kg
Wood Ø min. / max. 30 - 140 mm
Lenght if wood min. /
max.
300 - 1000 mm
Protection type IP 54
Protection class I
Subject to technical changes!
*Operating mode S2, short-term operation with con-
stant load.
The mode comprises of a start-up period, a time with
constant load and an idle time. The operating time is
10 mins, the relative duty cycle is 15% of the operating
time
Noise
m Warning: Noise can have serious e󰀨ects on your
health. If the machine noise exceeds 85 dB (A), please
wear suitable hearing protection.

Scheppach HS410 Specifications

General

Idle speed	- RPM
Product color	Black, Blue, Grey
Placement supported	Freestanding
Input power	2200 W
AC input voltage	230 V
Saw blade included	Yes

Weight and Dimensions

Depth	1080 mm
Width	780 mm
Height	250 mm
Weight	43600 g
Blade diameter	405 mm
