Scheppach OSM600 Instruction Manual

ww w.scheppach.com
26
|
GB
• When ordering please provide our article number as
well as type and year of manufacture for your equip-
ment.
m ATTENTION!
The device and packaging materials are not toys!
Children must not be allowed to play with plastic
bags, lm and small parts! There is a risk of swal-
lowing and su󰀨ocation!
8. Assembly / Before commissioning
m WARNING!
Always pull the power plug before making adjustments
to the equipment.
• All covers and safety devices have to be properly
tted before the equipment is switched on.
• It must be possible for the grinding/sanding belt and
disk to run freely.
• When working with wood that has been processed
before, watch out for foreign bodies such as nails
or screws, etc.
• Before you actuate the On/O󰀨 switch, make sure
that the abrasive paper is correctly tted and that
the equipment‘s moving parts run smoothly.
Connection to vacuum suction.
The use of an extraction system is recommended.
8.1. Tool changes (Fig. 3 - 8)
m ATTENTION! Turn o󰀨 the machine and discon-
nect the main plug.
When changing tools make sure to have all parts
cleaned.
Prepare the appropriate tool and mount it as follows:
1. Insert cover (6) in table (2)
2. Insert stage plate (8) into the cover (6) (Fig. 4)
3. Attach the lower spindle disc (7) to the spindle (1)
(Fig.5).
4. Slide the abrasive sleeve (9) onto the rubber
sleeve (7) (Fig. 5).
5. Apply the disc (D) (use the correct measurements)
(Fig. 7).
6. Put on the hex-nut and tighten it with the hook
wrench (F). (Fig. 8)
6. Technical data
Dimensions L x W x H 465x420x500 mm
Speed 2000 1/min
Oscillation stroke 16 mm
Belt dimensions 610 x 100 mm
Belt Speed 8 m/s
Grinding height max. 90 mm
Spindle ø 12.6 mm
Table Size 410 x 425 mm
Table Tilt 0° - 45°
Vacuum connector ø 38 mm
Weight 12.9 kg
Motor 220-240 V~ / 50 Hz
Power 450 W
Subject to technical changes!
Total vibration values determined in accordance with
EN 62841
sound pressure level L
PA
76 dB(A)
uncertainty K
pA
3 dB
sound power level L
WA
89 dB (A)
uncertainty K
WA
3 dB
Wear hearing protection.
The e󰀨ects of noise can cause a loss of hearing. Total
vibration values (vector sum - three directions) deter-
mined in accordance with EN 62841.
7. Unpacking
• Open the packaging and remove the device care-
fully.
• Remove the packaging material as well as the pack-
aging and transport bracing (if available).
• Check that the delivery is complete.
• Check the device and accessory parts for transport
damage. In the event of complaints the carrier must
be informed immediately.
• Later claims will not be recognised.
• If possible, store the packaging until the warranty
period has expired.
• Familiarise yourself with the product by means of the
operating instructions before using for the rst time.
• With accessories as well as wearing parts and re-
placement parts use only original parts.

Scheppach OSM600 Specifications

General

Brand	Scheppach
Model	OSM600
Category	Sander
Language	English
