16
Raincap Open Terminal
with Mesh
Tapered
Terminal
CONNECTING TERMINALS TO EXPANSION JOINT
The male spigot is pushed down inside the female form of the expansion joint, which
incorporates the standard Prima Plus female form. The joint is then secured using a Prima
Plus standard locking band, which is purchased separately.
TERMINALS
Raincaps are supplied with a locking band, other terminals are supplied without locking
bands. Where a locking band is being used then the terminal should be pushed into place
and the adjustment bolt on the locking band clip should be tightened to ensure that the
terminal is properly secured to the previous pipe.
Anti-Splash
Anti-Downdraught
Terminal
(Gastec Approved)
Chimney Lining Components
