Schiedel Prima Plus - Typical Installation

19
Typical Installation
SYSTEM CHIMNEY ON
INDUSTRIAL SPACE HEATER
Anti-Splash Terminal
1000mm Pipe
Storm Collar
200mm Pipe
200mm Pipe
200mm Pipe
Appliance
Connector
Adjustable Pipe
Adjustable Pipe
Wall Support
Top Plate
90˚ Tee
End Cap
with Drain
CONNECTING FLUE PIPE
ON CONDENSING BOILER
Appliance
Connector
Vertical
Drain
Inspection
Elbow
Measurement
Pipe
Adaptor to ICS
Trim Collar
ICS 93˚ Tee
Wall
Support
Adjustable
Top Plate
Cantilever
Support
Type 325
Tee Plug
with Drain
CHIMNEY LINER ON INSET FIRE
Cantilever Support
Type 325
Expansion Joint
Raincap & Locking
Band
Stove Adaptor
Pipe
Support Plate
Lowering Pipe
