1 Connect your source to the Magni’s “IN” RCA
jacks with high-quality RCA cables. Or you can
use crappy cables (but why?)
2 Connect the supplied wall-wart cable to the
jack labeled “14VAC.” Do not use any other
wall-wart, or bad things might happen.
3 Optional: Connect the preamp outputs to
powered monitors or an external power amp.
gettIng ConneCted
1
2
3
4
5
4 Turn on the switch. The protection relay will
mute the output for 15-20 seconds, then it will
engage with a click.
5 Select HI or LO gain, depending on your
headphones. IEMs and earbud style headphones
will probably need LO gain. If you don’t have
enough volume control range, use LO gain.
