Schlage L9486 - Fixed Outside x Turn Trim: L9460, L9480 Series

Service Manual L
31
Trim Assemblies
Fixed Outside x Turn Trim: L9460 x XL11-886*, L9480, LV9480, L9485, LV9485
* Actual lock function has a deadbolt only. Lock case and armor front shown with latch, auxiliary latch, and deadbolt.
NOTE: Standard full face mortise cylinder shown.
