Schlage L9486 - Wrought Knob Designs

L Service Manual
90
Trim Options
Wrought Knob Designs
Knobs shown with rose trim A or B. Also available with L or N escutcheons. See page 93-94 for escutcheon options.
41 42
Inside Knob Assembly Outside Knob Assembly
09-402 09-401
2¹⁄₄"
2³⁄₄"
2¹⁄₈"
2³⁄₄"
