Fix-EZ™ Installation Manual
MI-018CA
072216
© Schletter Canada Inc.
• 3181 Devon Drive • Windsor, Ontario N8X 4L3 • Tel: (519) 946 – 3800 • Fax: (519) 946 – 3805
E-mail: mail@schletter.ca • www.schletter.ca
Installation Tool List
• Tape measure
TX40
for installation of end caps
check hardware to determine drill bit size
• Chalk line
• Indelible marker
• Inclinometer
• Carpenters square
• Pliers
• Torx® bit (TX40)
• Hex head wrench
• 3/8” drive socket
• Drill bit
• Torque wrench
• Wrench and/or socket
• Rubber mallet
• Ratchet and/or rechargeable power drill
6 mm
for Rapid5k
TM
module clamps
for self-drilling screws
for standard module clamps
13 mm
15 mm
17 mm
18 mm
3/8”
for all bolted connection
• Chop saw
To Next Page
