PROLINE SINGLEFIX-V MOUNTING KIT | V1 | INSTALLATION GUIDE | 202102 3
SCHLETTER SOLAR GMBH | SUBJECT TO CHANGES
PROLINE SINGLEFIX-V MOUNTING KIT INSTALLATION GUIDE
TOOLS NEEDED
n Screwdriver with bit- and socket-wrench holder
n TX drive T40 bit
n 5W8 socket wrench
FURTHER REQUIRED DOCUMENTATION
n Calculation documents with schematic diagram, parts list and installation-related structural
analysis
n System structural analysis
TIGHTENING TORQUE
n Screw connections M8: 15 Nm
Exception: self-drilling screws: with depth stop
SAFETY INSTRUCTIONS
Planning, installation and commissioning of the solar power system must only be performed by
qualified technical personnel. Improper execution can result in damage to the system and
premises and endanger persons.
Falling hazard! Working on the roof as well as ascending and descending poses a risk of falling.
It is vital to observe accident prevention regulations and use appropriate fall protection
equipment. PV mounting systems do not meet the existing normative requirements for
climbing aids or fall protection measures. They are therefore neither suitable as climbing aids
nor as fall protection and must not be used for these purposes.
Injury hazard! Falling objects pose a risk of injury to people. Prior to installation, set up
barriers in the hazard area to warn people nearby.
Break hazard! PV modules may be damaged if stepped on or if handled inappropriately.
Electrical current hazard! Installation and maintenance of the PV modules must only be
performed by qualified technical personnel. Observe the safety instructions issued by the
PV module manufacturer!
