PROLINE SINGLEFIX-V MOUNTING KIT | V1 | INSTALLATION GUIDE | 202102 6
SCHLETTER SOLAR GMBH | SUBJECT TO CHANGES
Screws must not spin! Screw on until the screw sealing ring is lightly compressed.
Do not screw on the SingleFix in the trapezoidal sheet joint area.
Make sure that the SingleFix lies flat.
4. CREATE POTENTIAL EQUALISATION
n Connect module rows using perforated tape and self-drilling screws.
