Eco Function
Eco Function reduces the energy spent on unnecessary heating if you leave the
room/house during a scheduled heating event.
1. Tap the “Menu” button on the home screen.
2. Then tap the “User Settings” button to access the various user settings.
3. Tap the “Eco Function” button.
4. Tap the “OFF/ON” button to the setting you prefer.
5. Confirm your choice with “√” or discard it with “X”.
6. The thermostat will automatically return to “User Settings”.
With Eco Function enabled, the Scheduled Operation home screen is altered.
The lower left button, “Manual”, is changed to “Eco”.
Tap the “Eco” button to activate the Eco Function.
In Eco Mode, the thermostat enters an energy-saving state, in which the lowest
setback temperature in the event schedule is used as the temperature setpoint.
At the next scheduled event change, the thermostat returns to normal Scheduled
Operation.
Comfort
Manual
Boost
Frost Protect
Holiday
Comfort
Manual
Boost
Frost Protect
Holiday
Mon 11:15
11:00
24.5
°
Eco Other...
Mon 11:15
17:00
23.5
°
Manual Other...
1
Mon 11:15
17:00
23.5
°
Manual Other...
1
Heating Schedule
Energy Use
User Settings
Engineer Settings
Heating Schedule
Energy Use
User Settings
Engineer Settings
2
Child Lock
5
°
$
7
7
Display Brightness
Screen Saver
Energy Tariff
Eco Function
Date
Date Format
Time
Time Format
Dayl. Saving Time
Unit
Language
Information
Support
Child Lock
5
°
$
7
7
Display Brightness
Screen Saver
Energy Tariff
Eco Function
Date
Date Format
Time
Time Format
Dayl. Saving Time
Unit
Language
Information
Support
Child Lock
5
°
$
7
7
Display Brightness
Screen Saver
Energy Tariff
Eco Function
Date
Date Format
Time
Time Format
Dayl. Saving Time
Unit
Language
Information
Support
3
Eco Function
ON
4
5
>
<
