Temperature Scale 3/3
11. You can now set a Minimum Temp. Limit.
12. Use the “Up Arrow” or “Down Arrow” button to change the Minimum Temp.
Limit.
13. Confirm the setting with “√”.
14. You can now set a Maximum Temp. Limit.
15. Use the “Up Arrow” or “Down Arrow” button to change the Maximum Temp.
Limit.
16. Confirm the setting with “√”.
17. A confirmation screen will be displayed.
18. The thermostat will automatically return to “Engineer Settings”.
Temperature scale and
Limit calibrated
17
Maximum Temp. Limit
40°
14
15 1516
Minimum Temp. Limit
5°
11
12 1213
Minimum Temp. Limit
5°
11
12 1213
>
<
