CONGRATULATIONS on the purchase of your “ACE” light source! This light source
provides COOL, INTENSE WHITE light for all types of fiber optic illumination components and
either meets or exceeds the performance standards of all the safety certification agencies like UL,
ETL, CSA, and VDE. It was de-signed and is manufactured under the ISO 9000 guidelines.
The “ACE” light source provides a variable powered output of up to 150 watts of light from a
tungsten halogen lamp. The voltage-adjustable supply provides •1.0 to 21 VAC at 60 Hz. Lamp
intensity is controlled manually from the front panel. The removable Modulamp
®
assembly
contains the lampholder which supports three different bulb choices depending on intensity,
lifetime and uniformity requirements. The high output fan provides maximum airflow resulting in
extremely cool operation.
We suggest you read this manual carefully to become familiar with all the light source features
and how they work.
MAINTENANCE
Although your light source is designed to be maintenance free, it does contain sensitive
electronic parts. TREAT IT WITH CARE TO ASSURE BEST PERFORMANCE. The original
packaging should be used for protection, if you must ship the system.
CLEANING
The steel housing and the Lexan front and back plates have a durable finish that should retain
their original luster for many years. Clean exposed parts with any commercial glass cleaner. DO
NOT USE detergents, excess water, treated cloths, harsh cleaning agents or sprays. Use
cleaning fluid SPARINGLY. If you spill fluid into the interior, unplug the power cord and let the unit
dry thoroughly before using.
WARNING:
This product produces heat as a normal part of its operation. Hot lamp and internal surfaces can
