SCHOTT ACE Series - User Manual

19 pages

Save Page as PDF

To Next Page

Owner’s Manual

150 Watt

Tungsten Halogen

Light Source

CSA Listed to UL-1571

LIGHT SOURCE MODELS 115 VAC/60Hz 230 VAC/50Hz/60Hz

SOLID STATE RHEOSTAT

A20500 EKE Lamp

A20500.1 EJA Lamp

A20500.2 DDL Lamp

A20510 EKE Lamp

A20510.1 EJA Lamp

A20510.2 DDL Lamp

SOLID STATE RHEOSTAT

AND IRIS DIAPHRAGM

A20520 EKE Lamp

A20520.1 EJA Lamp

A20520.2 DDL Lamp

A20530 EKE Lamp

A20530.1 EJA Lamp

A20530.2 DDL Lamp

122 Charlton Street, Southbridge, MA 01550-1960

Main Page

Questions and Answers

S
Sharon CaldwellAug 3, 2025
What to do if the fan operates, but there is no light in SCHOTT ACE?
- S
  steven49Aug 3, 2025
  If the fan is working but the SCHOTT Laboratory Equipment light isn't, first ensure the power cord is fully inserted into the IEC connector on the rear panel and plugged into the correct power source. Inspect the power cord for any signs of damage. Then, check the fuse by removing the power cord, sliding out the fuse drawer, and testing the inner fuse for continuity. If blown, replace it ONLY with the fuse type specified on the rear panel. Also, if the unit feels warm, check for obstructions around the air intakes or exhaust; allow the unit to cool for 10 minutes before turning it back on, as it has a thermal cut-out device.
W
Willie MartinAug 18, 2025
What to do if neither the lamp nor the fan operates on SCHOTT ACE?
- C
  Craig LewisAug 18, 2025
  If neither the lamp nor the fan operates on your SCHOTT Laboratory Equipment, first ensure the power cord is fully inserted into the IEC connector on the rear panel and into the correct power source. Also, check the power cord for any damage. Next, examine the fuse: remove the power cord, slide out the fuse drawer, and check the inner fuse for continuity. Replace the fuse ONLY with the type specified on the rear panel if it's blown. If the unit feels warm, check for any obstructions to the air intakes or exhaust area. This light source has an automatic reset, thermal cut-out device for safety protection. Let the unit cool down for 10 minutes and turn it back on. If problems persist, consult qualified SCHOTT authorized service personnel.
