Operation
132
4.6 Configuration
You can adapt the conductivity meter to your individual
requirements. To do this, the following parameters can be
called up/changed (the status on delivery is marked in bold):
Note
You can leave the configuration menu at any time.
Parameters that have already been changed are stored.
To do this, press the <
ì> key.
Baud rate 1200, 2400, 4800. 9600
Data transmission inter-
val (Int 2)
OFF, 5 s, 10 s, 30 s,
1 min, 5 min, 10 min,
15 min, 30 min, 60 min
Calibration interval (Int 3) 1 ... 180 ... 999 d
AutoRange ARng yes, no
TREF 25/TREF 20 t25 or t20
Measured values given
as conductivity or resi-
stance values
S/cm or M
Ω
Temperature unit °C or °F
Date/time as required
1 Switch off the instrument.
2 Press and hold down the <
ì> key.
3 Press the <on/off> key.
The display test
appears briefly on the display.
The instrument then switches automatically to the
setting of the baud rate.
