Figure 2 Steering Worm Gear
Design for Navigator
Design for Well Installation
Plug screw with
dipstick
Hydraulic
motor
Rudder position
transmitter
Worm gear
Magnetic plug
(oil drain plug)
Second oil
drain plug
Oil level
sight glass
Rudder position
transmitter
Oil fill hole
Hydraulic motor
Magnetic plug
(oil drain plug)
