INTRODUCTION
FX-318 - FX212 08/21 Introduction Section 2-3
© 2021 Alamo Group Inc.
INTRODUCTION
The FX318/FX212 heavy duty rotary Cutter is designed primarily for weeds, grass, and
brush to 3-1/2” diameter. The side skirts are 13-5/8” deep. This additional room under the
deck, along with high blade tip speeds allows for a better cut and better material flow.
The one piece center shield allows for easy and full access to drivelines, clutches and
gearboxes on the center section.
Equipment Specifications
FX-318 FX-212
Cutting Width 216” 144” Blade Tip Speed (540 RPM)
Transport Width Center 15980 ft/min (4871m/min)
(Singles on Wings) 86” 90” Wing 16319 ft/min. (4974 m/min)
(Duals on Wings) 96” 95”
Blade Tip Speed (1000 RPM)
Transport Height 109” 109” Center 15974 ft/min (4869m/min)
Overall Width 228” 160” Wing 16581 ft/min (5054m/min)
Overall Length 208” 208”
Cutting Height 1.75” - 16.75” 1.75” - 16.75”
Gearbox Rating
(44.5mm - 425mm) Divider 260 HP (194 kW)
HP Required (min.) 75 HP (56 kW) 70 HP (52kW) Center & Wing 210 HP (157 kW)
Tractor HP 90 HP (67 kw) 85 HP (63kW) Limited Warranty 6 Year
Cutting Capacity (max) 3.5” (89 mm) 3.5” (89 mm)
Weight 5,800 lbs (2630 kg) 5,750 lbs (2614 kg)
Driveline
Hitch Weight 2350 lbs (1065 kg) 2234 lbs (1015 kg) Main (CV)
Tractor PTO Speed 540 or 1000 RPM 540 or 1000 RPM 540 RPM CAT 6 CAT 6
Cutting Capacity (Max) 3.5” (89mm) 3.5” (89mm) 1000 RPM CAT 5 CAT 5
Output Shaft 2.38” (60.3mm) 2.38” (60.3mm) Center & Wings CAT 5 CAT 5
Wing Working Range 25 down to 80 up 25 down to 80 up
Wing Floating Range 25 down to 30 up 25 down to 30 up
