6. TECHNICAL FEATURES
MODEL SRP 3005 Compact SRP 3008 Compact SRP 3010 II Compact
Pressure
Work
barg/psig 7,5/109 9/131 11/160 7,5/109 9/131 11/160 7,5/109 9/131 11/160
Volume
Flow
cfm 18,4 16,6 14 28,3 25,5 21 40 35 30
/min 521 470 396 801 722 595 1133 991 850
Drive method Belt Belt Belt
Power
Compressor
hp/kW 5/3,7 7,5/5,6 10/7,5
Voltage (V)
220 220 220/380
380 380 380/660
440 440 440/760
Start mode Partida direta Partida direta Estrela / triângulo
Electrical
Parameters
Fuse NH (A) 50 35 35 50 35 35 50 25 20
Command Voltage
(V)
220 380 440 220 380 440 220 380 440
Temperatura
Ambient
temperature
permitted (ºC)
0-40 0-40 0-40
Lubricant
oil
Volume (
) 2,7 2,7 2,7
Volume ( gal ) 0,7 0,7 0,7
Description Lub Schulz Lub Schulz Lub Schulz
Air discharge
connection
BSP (or Rp) 1/2” 1/2” 1/2”
Weight Liq.
Kg
With Tank 179 201 221
Without Tank
- - -
MODEL SRP 3010 Compact SRP 3015 ll Compact SRP 3015 Compact
Pressure
Work
barg/psig 7,5/109 9/131 11/160 7,5/109 9/131 11/160 7,5/109 9/131 11/160
Volume
Flow
cfm 40 35 30 59 51 45 59 51 45
/min 1133 991 850 1671 1444 1274 1671 1444 1274
Drive method Belt Belt Belt
Power
Compressor
hp/kW 10/7,5 15/11 15/11
Voltage (V)
220/380 220/380 220/380
380/660 380/660 380/660
440/760 440/760 440/760
Start mode Y∆ Y∆ Y∆
Electrical
Parameters
Fuse NH (A) 50 25 20 50 35 35 50 35 35
Command Voltage
(V)
220 380 440 220 380 440 220 380 440
Temperatura
Ambient
temperature
permitted (ºC)
0-40 0-40 0-40
Lubricant
oil
Volume (
) 5,2 5,2 5,2
Volume ( gal ) 1,4 1,4 1,4
Description Lub Schulz Lub Schulz Lub Schulz
Air discharge
connection
BSP (or Rp) 3/4” 3/4” 3/4”
Weight Liq.
Kg
With Tank 210 195 220
Without Tank -
- -
