3. Description
Hi Flow VX120 Motor
Included in the box:
1. Hi Flow VX120 motor (280W x 200H mm approx.)
Approx. 3 metre, 10amp cable and standard male plug
2. Fire resistant 100mm (110mm OD
1
) PVC riser pipe
Note: Cable cut-out at the bottom end only
3. Flexible ducting
Approx. 4 metres, 150mm (160mm OD
1
) diameter
4. Bell-mouth adoptor ring
150mm duct to 100mm riser
Not included in the box:
A. (Optional) Back draft shutter for 150mm ducting
Refer to page 13 for more information.
B. (Optional) Back draft shutter tment to bell mouth
adaptor Refer to page 14 for more information.
• Roof seal kit / Dektite
• Support straps for poly pipe which connects to the
roof truss
• Gaffer tape / electrical tape
• Zip ties
1
OD refers to outside dimension.
1 2
3
A
4
B
