A-CR-CCP-402/MB-001 SCHWEIZER 2-33 AOIs
2-1
SECTION 2 – LIMITATIONS
AIRSPEED LIMITATIONS
Gliders with a Max
Gross Weight of 1040
lbs
Gliders with a Max
Gross Weight of 1080
lbs
98 mph V
NE
Never Exceed Speed 100 mph
98 mph Max Dive Speed 100 mph
98 mph Max Air Tow Speed 100 mph
98 mph Max Speed (spoilers open) 100 mph
69 mph Max Auto / Winch Speed 70 mph
65 mph
1
V
A
Manoeuvring Speed
1
66 mph
1
50 mph Winch/Auto Launch Safety Speed 50 mph
Figure 2-1 Airspeed Limitations (updated 2016)
LIMIT LOAD FACTOR
Maximum Take-off Weight 1040 lbs 1080 lbs
Ultimate Load Factor
2
7.0 G
2
Limit Load Factor
1
4.67 G
1
Figure 2-2 Limit Load Factor (updated 2016)
CAUTION
1. Over 65 mph, the pilot must manoeuvre with caution.
Although the limit load factor of 4.67 G should never be exceeded,
the pilot can do so inadvertently with abrupt manoeuvres. Speeds
between 65 mph and the 98 mph (or 66 mph and 100 mph for
those gliders with gross weight of 1080 lbs) shall be treated as a
cautionary range and manoeuvring within this range should be
reduced to a minimum as velocity increases.
CAUTION
2. A safety factor of 1.5 is required for certification giving an
ultimate load factor of 7.0 G to allow for material variations and
inadvertent atmospheric conditions. Because of its light wing
loading, the 2-33 can develop very high loads if speed limitations
are not rigidly observed.
