Schwinn 230 - Page 15

15
7. Remove Hardware from Console
NOTICE : Do not crimp the cable.
Note: Hardware is pre-installed and not on the Hardware Card. *
*
X4
1
8. Connect Cables and Attach Console to Frame Assembly
NOTICE : Align the clips on the cable connectors and make sure the connectors lock. Do not crimp cables.
1
*
X4
#2
