8
Item Qty
Description
Item Qty
Description
A 8 Button Head Hex Screw, M8x20 F 2 Phillips Head Screw, M5x12
B 10 Button Head Hex Screw, M6x12 G 14 Lock Washer, M6
C 4 Flat Washer, M8 H 4 Curved Washer, M6
D 8 Lock Washer, M8 I 4 Phillips Head Screw, M6x25
E 10 Flat Washer, M6 J 4 Curved Washer, M8
HARDWARE / TOOLS
Tools
Included Not Included
(recommended)
4 mm
6 mm
A B C D E F
G H
I J
Note: Select pieces of Hardware have been provided as spares on the Hardware Card. Be aware that there may be
remaining Hardware after the proper assembly of your machine.
