FCC Compliance

Changes or modiﬁcations to this unit not expressly approved by the party responsible for compliance could void the

user’s authority to operate the equipment.

The machine and power supply comply with part 15 of the FCC rules. Operation is subject to the following two conditions:

(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including

interference that may cause undesired operation.

Note: This machine and power supply have been tested and found to comply with the limits for a Class B digital device,

pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful

interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if

not installed and used in accordance with the instructions, may cause harmful interference to radio communications.

However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful

interference to radio or television reception, which can be determined by turning the equipment off and on, the user is

encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

SAFETY WARNING LABELS AND SERIAL NUMBER

Serial Number

Product

speciﬁcation

WARNING!

• Injury or death is possible

if caution is not used while

using this machine.

• Keep children and pets

away.

• Read and follow all

warnings on this machine.

• Refer to the Owner’s

Manual for additional

warnings and safety

information.

• The heart rate displayed

isanapproximation

and should be used for

reference only.

• Not intended for use by

anyone under 14 years of

age.

•Themaximumuserweight

for this machine is 300 lbs

(136kg).

• This machine is for home

use only.
