Schwinn 700IC - Assembly; Attach Stabilizers to Main Frame; Attach Seat to Seat Post and Frame

9
1. Attach Stabilizers to Main Frame
Note: The hardware (*) is pre-installed and not in the Hardware Bag. If a tube is pre-installed in the stabilizer bracket,
remove and set it safely aside.
ASSEMBLY
2. Attach Seat to Seat Post and Frame
NOTICE: Make sure the adjustment knob (4a) engages the holes in the Seat Post.
1
2
3
*
*
*
X4
5
4
A
B
4a
