Schwinn a10 - Install Handlebars on Console Mast

10
5. Install Handlebars on Console Mast
Note: Hardware is pre-installed on Console Mast and not on Hardware Card.
NOTICE: Make sure the Handlebar Bracket (7a) has an equal distance between the two ends of the bracket and the
bracket mount on the Console Mast.
Donotcrimpthecables.
9a
X2
6mm
9
=
=
7a
7
