11
6. Install Console on Console Mast
Note: Remove the pre-installed screws from the back of the Console before you connect the cables.
NOTICE: Donotcrimpthecables.MakesurethattheswitchonthebackoftheConsoleissettoB (bike).
8
#2
7. Install Water Bottle Holder
Note: The hardware is pre-installed on the Console Mast and not on the hardware card.
12
X2
6mm
