Schwinn a25 - Assembly Instructions (Cont.); Pedal and Accessory Installation

12
9. Install Pedals
Note: The Left Pedal is reverse-threaded. Be sure to attach Pedals on the proper side of the Bike. Orientation is
based from a seated position on the bike. The Left Pedal has an “L”, the Right Pedal an “R”.
10. Install Water Bottle Holder
Note: Hardware is pre-installed on Console Mast and not on Hardware Card.
12 (R)
11 (L)
