13
9. Install Batteries in Console
Note:TheconsoleusesAAsizealkalinebatteries(UN-3).Makesurethatthebatteriespointinthedirectionofthe+/–
indicators in the battery bay.
!
Do not mix old and new batteries.
Do not mix alkaline, standard (carbon-zinc), or rechargeable (Ni-Cd, Ni-MH, etc) batteries.
10. Final Inspection
Inspect your machine to ensure that all hardware is tight and components are properly assembled.
NOTICE: Make sure the Seat Rail Locking Pin is engaged to ensure smooth operation. If the Level Adjustment Knob at the
junction of the Seat Rail Assembly and Main Unit is adjusted too low, the Seat Rail Locking Pin will not engage.
Turn the adjustment knob to increase the height.
Be sure to record the serial number in the field provided at the front of this manual.
Do not use or put the machine into service until the machine has been fully assembled and inspected for
correct performance in accordance with the Owner’s Manual.
+
-
X2
IM
Leveling the Machine
The machine needs to be leveled if your workout area is uneven. The Level Adjustment Knob is below the junction of the
Seat Rail Assembly and the Main Unit. To adjust:
1. Place the machine in your workout area.
2. TurntheLevelAdjustmentKnob(I)toadjustuntiltheSeatRailLockingPin(M)
engages securely.
Do not adjust the knob to such a height that it becomes unstable.
Injury to you or damage to the machine can occur.
Makesurethemachineislevelandstablebeforeyouexercise.
BEFORE YOU START
