Schwinn Rower - Page 12

12
7. Install the Console on the Mast
NOTICE: Remove the rubberbands from the cables and connect the cables from the mast to the Console cables. Do not
crimpthecables.Inserttheboltthroughtheholebetweentheribs(7a)onthesideoftheConsoleBracket.
8. Attach the Handle to the Pull Strap
NOTICE:PushtheHandleintothepullstraploop(1a).Removetheziptieandcardboardtubefromthepullstrap.Do not
allow the pull strap to retract by itself.
G
D F
8
1a
1a
