Schwinn Rower - Page 15

15
A Console G Seat Rail Assembly M Seat Rail Locking Pin
B Mast H Rower Engine N Lift Handle
C Handle I Level Adjustment Knob O Seat Assembly
D Pull Strap J Support Plates P Battery Compartment
E Resistance Adjustment Knob K Front Stabilizer Q TelemetryHeartRate(HR)
Receiver
F Foot Plate L Transport Roller
FEATURES
M
A
B
C
D
E
F
G
H
I
J
K
L
N
O
P
Q
WARNING! Use the values calculated or measured by the machine’s computer for reference purposes only. The
heart rate displayed is an approximation and should be used for reference only. Over exercising may
result in serious injury or death. If you feel faint stop exercising immediately.
