8
Tools
Included
5 mm
Item Qty Description Item Qty Description
A 1 SocketHeadCapScrew,M8x57 E 8 Spring Washer, M8
B 8 SocketHeadCapScrew,M8x20 F 2 Lock Nut, M8
C 1 Flat Washer, M8, Narrow G 1 HexHeadCapScrew,M8x90
D 9 Flat Washer, M8, Regular
HARDWARE / TOOLS
#2
13 mm
14 mm
15 mm
A B C D
E
F
G
6mm
