9
NOTICE: Do not remove the cardboard stop tube from the pull strap until thetimespeciedintheassemblysteps.
Do not remove rubberbands from the cables until thetimespeciedintheassemblysteps.
1. Attach Front Stabilizer to Main Frame
Note: Remove packaging material from the bracket and set it safely aside.
ASSEMBLY
2. Attach Foot Plate to Main Frame
Note: It may be easier to install the side screws and washers first, then the bottom screws and washers.
3
6mm
X4
B
D
E
1
2
6mm
X2
B
E
D
