Schwinn Rower - Page 10

10
3. Slide Seat onto Seat Rail Assembly and Install Bushings
Note:Thebushingsandhardware(*)arepre-installedandnotontheHardwareCard.RemoveziptiefromtheSeatRail.
4. Connect Wires from Seat Rail Assembly to Frame Assembly
Note: Remove rubberbands from the cables on the Seat Rail Assembly. Do not crimp the cables.
4
5
*
*
6mm
5mm
