Corrective Action against Leaks from Cell Window

1. In case of liquid leaks from the flow cell window, first use a laboratory wiper to soak up the leak, and then

firmly tighten the cell window fixing screw (groove width 1 mm, groove length 8 mm) clockwise with a

flat-bladed screwdriver.

2. If the leak does not stop even after tightening the screw, contact your SCIEX representative.

Figure 6-1 Corrective Action Against Leaks from Cell Window

DescriptionItem

Flow cell1

Cell window fixing screw2

Operator GuideExionLC™ PDA Detector

RUO-IDV-05-1842-B40 of 47

Troubleshooting
