DescriptionItem
D2 (D2 lamp). Illuminates when the D2 lamp is turned on. The LED blinks while the lamp is
warming up.
1
CONNECT. Illuminates when the module is connected to the system controller and the computer.2
Status indicator:
• Green: Power is on
• Red: Error
• Orange: In sleep mode
3
ExionLC™ PDA DetectorOperator Guide
45 of 47RUO-IDV-05-1842-B
Status Panel
