Scooterpac Ignite | User Manual 15
7.3 Seat Adjustments
It is important to adjust the seat into a good position that allows you to
comfortably operate all the vehicle controls.
Forward/Backwards
To move the seat forwards or backwards, grasp the black lever on the
right-hand side underneath the seat whilst sitting down.
Push firmly against the floor with your feet or pull on the handles
mounted to the doors.
TOP TIP – Do not use the control tiller to push or pull yourself.
Backrest Adjustment
The pitch of the seat can be changed by the lifting lever located on the
right-hand side of the seat when seated.
Figure 3 – Pull black handle to adjust the
seating position
Figure 4 – Pull black handle to adjust the
backrest
