Scosche FCJ2076 - Page 14

1987-96 Dodge Dakota
Read pages 2-4
RADIO REMOVAL:
for kit assembly.
1. Remove eight screws from the dash trim panel.
2. Remove two screws from the underside of the steering
column trim, and remove the rim.
3. Remove two screws from the radio mounting bracket, disconnect power antenna,
speaker leads, and all other electrical connections, and remove the radio.
USE THESE SUPPORT
TABS AS REQUIRED
#2190 PANEL
REMOVE ALIGNMENT
Usar tantas de estas
PIN - BOTTOM
pestañas como sea
Sacar la clavija de
necesario
alineamiento - Inferior
USE THIS BRACKET
Usar este braquete
USE THE SHADED MOUNTING TABS AND THE INDICATED BRACKETS. CUT OFF THE REMAINING TABS
AND DISCARD. FOR DIN ISO INSTALLATION, SEE PAGE 4.
Usar las pestañas sombreadas y los braquetes indicados. Cortar las pestañas restantes y descartarlas.
Para la instalación de radios DIN ISO ver la página 4.
1990-93 Dodge Daytona
Read pages 2-4
RADIO REMOVAL:
for kit assembly.
1. Pull firmly outward on the console/radio trim panel
- secured by five metal spring clips, two at the top,
two on the right side and one on the left side.
2. Extract the top two screws from each side of the lower console - this allows you to slightly
spread the console, providing clearance to remove the radio.
3. Remove the remaining two screws securing the radio, disconnect the connectors
and remove the radio.
#2190 PANEL
REMOVE ALIGNMENT
TABS AS REQUIRED
USE THESE SUPPORT
PIN - BOTTOM
Sacar la clavija de
pestañas como sea
Usar tantas de estas
alineamiento - Inferior
necesario
USE THIS BRACKET
Usar este braquete
USE THE SHADED MOUNTING TABS AND THE INDICATED BRACKETS. CUT OFF THE REMAINING TABS
AND DISCARD. FOR DIN ISO INSTALLATION, SEE PAGE 4.
Usar las pestañas sombreadas y los braquetes indicados. Cortar las pestañas restantes y descartarlas.
Para la instalación de radios DIN ISO ver la página 4.
1995-99 Dodge Neon
Read pages 2-4
for kit assembly.
1995-99 Plymouth Neon
RADIO REMOVAL:
1. Remove the ashtray from the dash.
2. Carefully pry outward on the radio trim bezel to release spring clips then remove.
3. Extract the two 3/8'' screws securing the radio to the dash, pull the radio from the dash cavity,
unplug all connectors, disconnect the ground strap and remove the radio.
USE THESE SUPPORT
TABS AS REQUIRED
#2190 PANEL
REMOVE ALIGNMENT
PIN - BOTTOM
Usar tantas de estas
Sacar la clavija de
pestañas como sea
alineamiento - Inferior
necesario
USE THIS BRACKET
Usar este braquete
USE THE SHADED MOUNTING TABS AND THE INDICATED BRACKETS. CUT OFF THE REMAINING TABS
AND DISCARD. FOR DIN ISO INSTALLATION, SEE PAGE 4.
Usar las pestañas sombreadas y los braquetes indicados. Cortar las pestañas restantes y descartarlas.
Para la instalación de radios DIN ISO ver la página 4.
14
