Page 4
2.0 GENERAL MACHINE INFORMATION
2.1 MACHINE IDENTIFICATION DATA
Model: _________________ SU-280
Serial number: ___________
Manufacture year: ________
NOTE: In order to request replacement parts, whether they are covered by the warranty or not,
always state the model and serial number of the machine, as well as the name of the part and the
code that appear in the last chapter of exploded views.
3.0 TECHNICAL DATA
MAIN MOTOR POWER TRIF. 2 VEL.- MONOF. 1.5 HP
MOTOR SPEED3000/1500 RPM - 3,000/1,500 RPM - 1,500 RPM
SHAVINGS PUMP POWER 0,09 Kw/0,12 CV
CUTTING SPEED 80/40 m/min - 262/131 ft/min
ANGLE OF CUT 30° RIGHT
BAND SAW BLADE DIMENSIONS 96.5 X 1"
CUT THICKNESS 1.5mm
CLAMP; MAXIMUM OPENING 290 mm 11.5 INCHES
3.1 NOISE LEVEL
At a distance of 60 cm RUNNING OFF-LOAD 62 dB (A) Leq
MACHINING A 70x50 PROFILE 83 dB (A) Leq
