GENERAL INFORMATION AND INSTALLATION
A. INTRODUCTION
This manual provides the specifications and the
step-by-step procedures for the installation, start-
up and operation, maintenance and cleaning for
the SCOTSMAN MF 26, MF 36, MF 46, MF 56
and MF 66 Modular Icemakers.
The Electronic Flakers and Superflakers are
quality designed, engineered and manufactured.
Their ice making systems are thoroughly tested
providing the utmost in flexibility to fit the needs
of a particular user.
4. On models MF 26, MF 36, MF 46 and MF 56
remove the top and front panel while on model
MF 66 remove top and sides panels of the unit
and inspect for any concealed damage. Notify
carrier of your claim for the concealed damage
as stated in step 2 above.
5. Remove all internal support packing and
masking tape.
6. Check that refrigerant lines do not rub
against or touch other lines or surfaces, and that
the fan blades move freely.
7. Check that the compressor fits snugly onto
all its mounting pads.
8. See data plate on the rear side of the unit
and check that local main voltage corresponds
with the voltage specified on it.
CAUTION. Incorrect voltage supplied to
the icemaker will void your parts
replacement program.
9. Remove the manufacturer’s registration
card from the inside of the User Manual and fill-
in all parts including: Model and Serial Number
taken from the data plate.
Forward the completed self-addressed registra-
tion card to SCOTSMAN EUROPE/Frimont
factory.
Storage bin (SB Series)
1. Follow the steps 1, 2 and 3 above to
unpack the storage bin.
2. Unloose the two bolts and remove the protec-
tion plate from the drain fitting on model B 550 S.
3. Carefully lay it down on its rear side and fit
the four legs into their sockets.
4. Remove all internal support packing and
masking tape as well as the plastic ice cube
deflector which is not used with the SCOTSMAN
Modular Flakers.
5. Remove the manufacturer’s registration
card from the inside of the User Manual and fill-
in all parts including: Model and Serial Number
taken from the data plate.
Forward the completed self-addressed registra-
tion card to SCOTSMAN EUROPE/Frimont
factory.
Storage bin (UBH Series)
1. Follow the steps 1, 2 and 3 above to
unpack the storage bin.
NOTE. To retain the safety and performance
built into this icemaker, it is important that
installation and maintenance be conducted
in the manner outlined in this manual.
Storage Bin
Since the MF series Modular Flakers do not have
their own attached ice storage bins, it is necessary
to use an auxiliary bin as detailed here below:
SB 193 S or SB 322 S in combination with
MF 26 and MF 36
SB 393 S or SB 530 S with its companion
CBT 30 EFSD Top Cover in combination with
MF 26, MF 36, MF 46 and MF 56
SB 550 S with its companion CBT 42 EFSD
Top Cover in combination with MF 46 and MF 56
SB 948 S with its companion CBT 48 FMCD
Top Cover in combination with MF 46 and MF 56
SB 1025 S with its companion CBT 52 FMCD
in combination with MF 46 and MF 56
UBH 1100 or UBH 1600 in combination
with MF 46, MF 56 and MF 66.
B. UNPACKING AND INSPECTION
Icemaker
1. Call your authorized SCOTSMAN Distributor
or Dealer for proper installation.
2. Visually inspect the exterior of the packing
and skid. Any severe damage noted should be
reported to the delivering carrier and a concealed
damage claim form filled in subjet to inspection of
the contents with the carrier’s representative
present.
3. a) Cut and remove the plastic strip securing
the carton box to the skid.
b) Cut open the top of the carton and remove the
polystyre protection sheet.
c) Pull out the polystyre posts from the corners
and then remove the carton.
