Scotsman C0322 - Product Description & Electrical Requirements

C0322 through C1030 E Series
Air and Water Cooled User Manual
October 2014
Page 4
Product Description & Electrical Requirements
Dimensions w" x d" x h" Model Series Electrical
volts/Hz/
phase
Condenser Minimum
Circuit
Ampacity
Maximum
Fuse Size*
22.6** x 24 x 23
C0322SA-1 E 115/60/1 Air 12.7 15
C0322SW-1 E 115/60/1 Water 11.9 15
C0322MA-32 E 208-230/60/1 Air 6.1 15
C0522SA-1 E 115/60/1 Air 13.5 15
C0522SW-1 E 115/60/1 Water 11.9 15
C0522SA-32 E 208-230/60/1 Air 6.5 15
C0322MA-32 E 208-230/60/1 Air 6.1 15
30.6** x 24 x 23
C0330SA-1 E 115/60/1 Air 12.7 15
C0330SW-1 E 115/60/1 Water 11.9 15
C0330MA-32 E 208-230/60/1 Air 6.1 15
C0530SA-1 E 115/60/1 Air 15.2 20
C0530SW-1 E 115/60/1 Water 13.5 15
C0530SA-32 E 208-230/60/1 Air 7.8 15
C0530MA-32 E 208-230/60/1 Air 7.8 15
C0630SA-32 E 208-230/60/1 Air 18.2 20
C0630SW-32 E 208-230/60/1 Water 17 20
22.6** x 24 x 29 C0722SA-32 E 208-230/60/1 Air 11 15
30.6** x 24 x 29
C0830SA-32 E 208-230/60/1 Air 10.2 15
C0830SW-32 E 208-230/60/1 Water 9 15
C0830SA-3 E 208-230/60/3 Air 8.4 15
C1030SA-32 E 208-230/60/1 Air 12.2 15
C1030SW-32 E 208-230/60/1 Water 11 15
* Or HACR type circuit breakers.
** Maximum width at top panel.
