Scotsman C1448R - Condenser and Machine Layouts

C1448, C1848, C2148
Remote Condenser Models - User Manual
November 2006
Page 5
.88 DIA. ELECTRICAL
INLET
.65 in
1.7 cm
27.56 in
70.0 cm
2.84 in
7.2 cm
AIR FLOW
.562 DIA.
MOUNTING
HOLES (4)
23.54 in
59.7 cm
LIQUID LINE
3/8" MALE CPLG.
DISCHARGE LINE
1/2" MALE CPLG.
14.56 in
36.9 cm
7.60 in
19.3 cm
29.19 in
74.1 cm
24.71 in
62.7 cm
28.07 in
71.2 cm
29.50 in
74.9 cm
38.47 in
97.7 cm
35.72 in
90.7 cm
2.75
29.15 in
74.0 cm
32.32 in
82.1 cm
11.50 in
29.2 cm
15-0782-01 CAN CAUSE INJURY OR DEATH:DISCONNECT ALL REMOTE ELECTRICPOWER SUPPLIES BEFORE SERVICING. RISK OF ELECTRIC SHOCK^M WARNING
Cond. Fins
LEFT SIDE VIEW
FRONT VIEW
REMOTE COOLED
BACK VIEW
PLAN VIEW
48.00
121.9
29.00
73.7
48.89
124.2
.92
2.3
24.00
61
1.57 REFRIGERATION
AND ELECTRICAL CHASE
18.00
45.7
46.17
117.3
20.59
52.3
6.11
15.5
2.96
7.5
24.06
61.1
24.76
62.9
24.93
63.3
24.20
61.5
8.33
21.2
11.87
30.2
3/8" FPT
WATER
INLET
REMOTE CONDENSER
DISCHARGE LINE
1/2 MALE CPLG.
.88" DIA
ELECTRICAL
ACCESS (2)
REMOTE CONDENSER
LIQUID LINE
3/8 MALE CPLG.
3/4" FPT
DRAIN
9.00
22.9
2.00
5.1
9.63
24.5
48.00 REF.
24.00
REF.
22.75
MINIMUM BIN
TOP OPENING
57.8
18.30
46.5
ICE DROP OPENING
Condenser and Machine Layouts
